Modern Steel Poultry House Egg Collection System for Laying Hens

Name: Modern Steel Poultry House Egg Collection System for Laying Hens
Brand: Qingdao KXD Steel Structure Co., Ltd
SKU: KXD-POULTRY HOUSE
Price: 55.00 USD
Availability: InStock

Chi tiết sản phẩm

Place of Origin: China

Hàng hiệu: KXD

Chứng nhận: CE, ISO 9001, ISO140001, ISO45001

Model Number: KXD-POULTRY HOUSE

Điều khoản thanh toán và vận chuyển

Minimum Order Quantity: 200 square meters

Giá bán: 30-80 USD per sqm

Packaging Details: Steel Pallet Or In Bulk

Delivery Time: 35-55 days

Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability: 15000 tons Per Month

Nhận được giá tốt nhất

Chi tiết sản phẩm

Mô tả sản phẩm

Chi tiết sản phẩm

Làm nổi bật:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Modern Steel Poultry House, Steel Chicken Egg Collection System


Name:	Steel Poultry House	Material:	Q345 Q235 Steel Structure
Roof:	Sandwich Panel, Galvanized Steel Sheet	Door:	Steel Insulation Door
Window:	Aluminum	Connections:	Bolts Connection
Surface Coat:	Galvanized	Beam:	H Section Steel
Column:	H Section Steel	Color:	Customized
Wall:	Sandwich Panel	Dimensions:	Customized
Design:	Customized	Standard:	ASTM, DIN, GB, JIS
After-sale Service:	Onsite Installation, Onsite Inspection, Free spare parts	Chứng nhận:	ISO9001&CE Certification
Application:	Chicken Shed, Piggery House, Cattle Shed etc.

Name:	Steel Poultry House
Material:	Q345 Q235 Steel Structure
Roof:	Sandwich Panel, Galvanized Steel Sheet
Door:	Steel Insulation Door
Window:	Aluminum
Connections:	Bolts Connection
Surface Coat:	Galvanized
Beam:	H Section Steel
Column:	H Section Steel
Color:	Customized
Wall:	Sandwich Panel
Dimensions:	Customized
Design:	Customized
Standard:	ASTM, DIN, GB, JIS
After-sale Service:	Onsite Installation, Onsite Inspection, Free spare parts
Chứng nhận:	ISO9001&CE Certification
Application:	Chicken Shed, Piggery House, Cattle Shed etc.

Mô tả sản phẩm

Modern Steel Poultry House Egg Collection System for Laying Hens

Product Specifications

Name	Steel Poultry House
Material	Q345 Q235 Steel Structure
Roof	Sandwich Panel, Galvanized Steel Sheet
Door	Steel Insulation Door
Window	Aluminum
Connections	Bolts Connection
Surface Coat	Galvanized
Beam	H Section Steel
Column	H Section Steel
Color	Customized
Wall	Sandwich Panel
Dimensions	Customized
Design	Customized
Standard	ASTM, DIN, GB, JIS
After-sale Service	Onsite Installation, Onsite Inspection, Free spare parts
Certification	ISO9001&CE Certification
Application	Chicken Shed, Piggery House, Cattle Shed etc.

Poultry Shed Farm Design

Modern Chicken Farm Chicken Cage Egg Collection System with Manure System and Environment Control Technology for Laying Hens

Broiler Feeding on Ground

Main Steel Frame: Includes H section Column & Beam, Purlins, Support, Angel Steel etc.
Roof & Wall Cladding: Roof & Ceiling, Wall Panel, Fiberglass Wool as Roof Insulation, Ridge Tile, Trim Coverage and Screws etc.
Door & Window: Steel Insulation Door & Aluminum Window and Trims
Fastener: Foundation Bolts, Bolt and Nuts etc.
Equipment: Cages (H Type and A Type), Feeding System, Manure-Removing System, Cooling and Ventilation, Lighting System, Environment Controlling System

Broiler & Layers Feeding in Cages

A variety of cages to meet different housing construction spans
Frame structure ensures overall stability with sheet metal wear-stress to prevent mesh deformation
Main frame made from 275g hot-dip galvanized sheet for strength and rust resistance
Fully open cage door structure reduces chicken wing breakage during handling
Double-layer scraping structure ensures thorough manure separation
Hot-dip galvanized mesh after welding for corrosion resistance and 10-15 year lifespan

Product Advantages

Reasonable Design

3-4 Tiers Battery Cage with optimal height for easy monitoring
Open design promotes natural ventilation

High Quality Equipment with 20 Years Service Life

Q235 High Quality Steel Material from brand manufacturers
275g/m² Hot-dip galvanized steel for superior corrosion resistance
Numerical Control Process Technology for high precision and smooth operation

Stronger Equipment for Safety

2.15mm High Quality Steel Mesh with excellent weight-bearing capacity
Two Reinforcing Ribs at Each Bottom Mesh for 50kg/㎡ load-bearing capacity

Comfortable Feeding Environment

450cm²/bird space allocation for healthier chickens
Top mesh prevents birds from pecking manure and scurrying
Sliding grids for easy bird movement without escape

Safer Feeding Environment

Bottom Mesh with 8° slope for gentle egg rolling
PVC Egg Baffle prevents chicken egg pecking

Feed Cost Savings

Deep 'V' Feed Trough with Inner Rim reduces feed waste
Two material options to meet different requirements

Environmental System

Our environment control system features chicken growth temperature curve, minimum air volume curve, light curve, with automatic control for crosswise and lengthwise ventilation. It controls exhaust fans, heater stoves, curtains, cooling pads, light systems and feeding lines. The system can be monitored and managed remotely via mobile phone.

Heating System

Intelligent control, high efficiency and energy saving, with fast warming capability. Safe and durable equipment provides stable heating for livestock and poultry houses. Versatile installation options including outside the house, on the floor or suspended indoors.

Our Services

Custom design plans and detailed approval drawings using Tekla, PKPM, 3D3S software
Steel structure buildings consultation service
Budget planning assistance
Precision fabrication
Onsite erection & installation guidance
Transportation & delivery coordination

Why Choose Qingdao KXD Steel Structure Co., Ltd.

High Grade Production Quality: Strict quality control system ensures high-quality projects
Mature Technological Strength: Continuous R&D of new products, technologies and processes
Comprehensive Product System: Complete solutions for poultry farming needs
Exquisite Service Level: Detailed pre-sales consulting, installation, and after-sales services
Broad Business Scope: Global sales and service network with worldwide recognition
